IP等级/IP Code 实验项目/Test Item 产品型号/Type 主要规格及参数 Specification and Parameter
GB4208:IPX1
ISO20653:IPX1
垂直滴水试验
Vertical Drop Test
IP-L-D1 台面尺寸Table Size:1000×1000
滴水量Drop Flow:1mm/min
GB4208:IPX2
ISO20653:IPX2
倾斜滴水试验
Tilt Drop Test
IP-L-D2 台面尺寸Table Size:1000×1000
滴水量Drop Flow:-3~5mm/min
GB4208:IPX3
ISO20653:IPX3
淋雨试验(喷水试验)
Rain Test (Spraying Test)
IP-L-B
摆杆半径 Pendulum Rod Rdius:
R200/R400/R600/R800/R1000/R1200/R1400/R1600 喷水孔径Blowhole Diameter:0.4mm
总水流量Total water Flow:0.56~7.0L/min

GB4208:IPX4
ISO20653:IPX4
淋雨试验(喷水试验)
Rain Test (Spraying Test)
GB4208:IPX4K
ISO20653:IPX4K
增压溅水
Pressurized Splashing Water

喷水孔径:Blowhole Diameter:0.8mm
流量:water Flow:0.6L/min/hole
水压:Water Pressure:~400kpa

GB4208:IPX5
ISO20653:IPX5
喷水试验
Spraying Test
IP-LP
喷嘴直径Nozzle Diamete:6.3mm
喷水距离Spraying Distance:2.5~3mm
流量Water Flow:12.5L/min

GB4208:IPX6
ISO20653:IPX6
压力喷水试验
Water Pressure Spraying

喷嘴直径Nozzle Diamete:12.5mm
喷水距离Spraying Distance:2.5~3mm
流量Water Flow:100L/min

GB4208:IPX6K
ISO20653:IP6K
增压喷水试验
Pressurized Jet Test

喷嘴直径Nozzle Diamete:6.3mm
喷水距离Spraying Distance:2.5~3mm
流量Water Flow:100L/min

GB4208:IPX7
ISO20653:IP7K
浸水试验
Immersion Test
IP-L-J
浸入深度Immersion depth:0.15~1.0m

GB4208:IPX8
ISO20653:IPX8
压力浸水试验
Pressurized Immersion Test
IP-L-Y
压力Pressure:0~1.65Mpa

GB4208:IPX9K
ISO20653:IP9K
高温高压喷水试验
High Pressure/Steam Jet Test
IP-J-G

扇形喷嘴:Sector Type Nozzle
喷射角度:Jet Angle:0°、30°、60°、90°
水流量:Water Flow:14~16L/min
水压:Water Pressure:8000~10000kpa
水温:Water Temp:80±5℃

ISO16750-4 盐水试验、泥水试验
Mud test、Salt Test

根据要求定制Customizing


备注
1.设备性能在环境温度+25℃,相对湿度65%RH下,无负载所测。The performance vulues refer to environmental +25℃ 65%RH,no loading.
2.外形尺寸未包含局部突出部分。The ledge is not included in the overall dimensions.
